ZH-VF40 Target Drone
| Item | Specification |
|---|---|
| Wingspan | 3300 mm |
| Length | 2500 mm |
| Height | 750 mm |
| Maximum take-off weight (MTOW) | 40 kg |
| Fuel tank capacity | 12 L |
| Maximum payload | 15 kg |
| Endurance | 560 min @ 5 kg |
| Maximum flight speed | 160 km/h |
| Cruising speed | 90–150 km/h |
| Rate of climb | ≤ 3.5 m/s |
| Rate of descent | ≤ 1.5 m/s |
| Service ceiling | 6000 m |
| Wind resistance | Level 5 (vertical takeoff/landing phase) / Level 6 (cruise phase) |
| Operating temperature | -10 °C to +45 °C |
| Folded / disassembled dimensions (L × W × H) | 1670 × 680 × 750 mm |
