| Product Parameters |
| Item |
Specification |
| Frame |
10-inch frame |
| Frame type |
X-B type |
| Flight controller (FC) |
FC405A ICM42688 |
| ESC (electronic speed controller) |
65A 4-in-1 ESC |
| VTX (image transmission) |
5.8G, 3W (optional) |
| Antenna |
5.8G, 151 mm, 3.5 dBi |
| Camera |
1500TVL, 165° wide-angle (optional) |
| Motors |
3115-900K motors |
| Propellers (blades) |
1050 × 3 |
| Receiver |
ELRS 915 MHz |
| Drone weight (single unit) |
800 g |
| Maximum flight speed |
140 km/h |
| Rated payload |
3.5 kg |
| Maximum payload |
4.8 kg |
| Maximum take-off weight |
6.3 kg |
| Recommended battery |
6S 8500mAh, XT60 plug |
| Flight time (rated load, 8500mAh) |
≈ 9 min |
| Flight time (rated load, 10000mAh) |
≈ 11 min |
