| FPV Drone Specifications |
| Item |
Specification |
| Frame |
10 inch Frame Mark4 V2 |
| Frame type |
X type |
| Flight controller (FC) |
F405 V3 |
| ESC |
65A 4-in-1 ESC, 6S |
| VTX |
5.8G, 3W |
| Antenna |
5.8G, 151 mm, 3.5 dBi |
| Camera |
1200TVL, 165° wide angle (optional) |
| Motors |
3115 900KV motors |
| Propellers |
1050 × 3 |
| Receiver |
ELRS 915 MHz |
| Drone weight |
800 g |
| Maximum flight speed |
140 km/h |
| Rated payload |
3.0 kg |
| Maximum payload |
4.0 kg |
| Maximum take-off weight |
6.5 kg |
| Recommended battery |
6S 8500mAh, XT60 plug |
| Flight time (rated load, 8500mAh) |
≈ 9 min |
| Flight time (rated load, 10000mAh) |
≈ 11 min |
